Figure 27. Composite section for Site 1081. Magnetic susceptibility and color reflectance (red/blue ratio [650 nm/450 nm]) are plotted for Holes 1081A (thick black line), 1081B (gray line), and 1081C (thin black line). The downhole logs are shown in meters composite depth (mcd). Offsets have been applied for clarity.

Figure 27. Composite section for Site 1081. Magnetic susceptibility and color reflectance (red/blue ratio [650 nm/450 nm]) are plotted for Holes 1081A (thick black line), 1081B (gray line), and 1081C (thin black line). The downhole logs are shown in meters composite depth (mcd). Offsets have been applied for clarity.
